Description
Fiat Tipo 2. 0 16v Sedicivalvole
Originally built for racing use in Germany in the 90s. Late 90s this was in use in Finnish Sport2000 racing series.
After that i have been driving it in Finnish Historic Race Finland series at Roadsport 2B class from 2016->
New engine, 2h driven:
ZRP Billet crankshaft and H-profile rods with ARP Custom Age 625+ bolts
Supertech valves, exhaust valves made from inconel
King racing bearings
CPS pistons, 12:1 compression
Catcams custom made camshafts with adjustable pulleys etc.
Cylinder head ported by Kansiset with ARP racing bolts
Projoe Lancia Delta Integrale upgraded chromoly oil pump
Cold air intake custom made from carbon fibre with ITB:s
Custom made exhaust manifold with cerakote coating and heat wrap
Transmisson:
Bacci Romano racing gearbox with limited slip differential
TTV racing 184mm race flywheel ~3kg with Helix 184mm cerametallic racing clutch.
Gearbox oil cooler with electric pump
Coolerworks shifter
Hydraulic clutch
Brakes and suspension:
Brembo 4 piston calipers with 305mm ventilated discs
2 piston calipers at rear with solid disc
Tilton 600-Series firewall mount aluminum pedal assembly
Öhlins 1-way shocks at front and Koni 3012 2-way racing shocks at rear
Group A Chromo tubular lower wishbones with uniball ends. Made by Rally Corsa Shop.
Chassis
Quick steering rack with Krontec quick release, rotary+buttons
Body completely gone through
Heated windscreen
Carbon fibre bonnet
Bosch 044 and carter fuel pumps. Fuel and brake lines with AN connectors all the way.
Electrics:
Professional WRC-grade wiring loom with Deutsch Autosport connectors, Tefzel wiring with Raychem DR-25 heatshrink. Keller Brake pressure sensors front and rear, steering angle sensor, usb-chargers for action cameras and additional tablets etc. Pass through connectors at firewall for quick removal and service.
I am electrician at Toyota Gazoo Racing WRC-team so i can say that these are made with thought. I have all the wiring layouts and pinouts in PDF so you get them with you after buying.
Motec PDM32 with autosport connectors
AIM MXL Pista Datalogger/ Dash, with shift lights
Maxxecu sport ECU
Motometer electronic main switch, Apem switches in and out.
Super B Lifepo4 20Ah light racing battery
